What makes Magnum's Designer Series unique?

• The Industry’s highest quality braid in five color choices to compliment your bike:  STERLING CHROMITE^®, BLACK PEARL, POLISHED STAINLESS, COPPER CANYON and KARBONFIBR.

• KARBONFIBR braid is created from distinct black tone colors, blended and interwoven in such a way that it mimics the look of high-tech carbon fiber.
• Braid color and weave match on all MAGNUM control cables and brake lines.
• Kits to fit most Harley-Davidson Models - Touring, Softail, Dyna, Sportster, and Trikes.
• Brake lines are constructed with PTFE inner tubing, DuPontTM Kevlar® aramid fiber, premium Signature Magnum braids, and an outer PVC jacket.
• Kits consist of a direct fit lower assembly used in conjunction with alternative length upper lines with choice of 35°, 90°, or 180° banjo angles to ensure a great fit.
• -3AN connections for easy installation.
• All fittings are highly polished and chrome or black chrome plated.
• Crystal clear outer jacket offers exceptional protection against scuffing paint or chrome and will never discolor.
• Inner PTFE tubing braided with Aramid Fiber reinforcement provides the ultimate in high performance by greatly reducing line expansion and are designed to be compatible with Harley-Davidson ABS requirements for stock and alternative length brake lines.
• Compliant with all DOT FMVSS-106 requirements.
• Assembled in the USA.


DuPontTM and Kevlar® are trademarks or registered trademarks of E.I. du Pont de Nemours and Company.

Important Notes:

• Magnum Shielding brake lines are designed to follow the same routing path as OEM lines.
• Upper, lower, mid brake line and adapter kits are sold separately for a perfect fit.
• Single and Dual Disc Dyna and Sportster models use two kits - one upper and one lower.
• Softail models use 3 kits (except 2018+ dual disc), with the lower kit being optional.  Upper kits are required for handlebar changes; by using either an upper brake line adapter or for 11-17 Softail models, the optional ABS Lower Brake Line which includes an adapter.
• Lower kits for 2018+ Softail models do NOT include an adapter.
• Adapter for Softail models allows the upper brake line to complete the connection from the ABS controller (2011-2017) or lower brake line (2018+) to the master cylinder.

• If replacing the stock lower brake line assembly on 2018+ dual disc Softails, an adapter is NOT needed.  Using -3AN fittings, the upper line connects directly to the Magnum Lower assembly.
• Dual disc Touring models use three kits - one upper, one lower, and one mid-line.
• Trike models use two kits - one upper and one mid-line.  No lower is available.

• A Designer mid-line and upper line is required for all Touring and Trike models with ABS.  The mid-line connects to the upper brake line in the fairing or nacelle and completes the routing from the master cylinder to the ABS controller.  A lower kit is optional.
• 2018+ Dual Disc Softail models require an Upper Brake Line Adapter and upper brake line.  A lower is not needed.
• Non-stock applications require taking a measurement for upper brake line length and banjo angle to ensure correct fitment.  Please read the "View Our Guide" sections of each product category to find out how to measure correctly.
• Harley-Davidson motorcycles equipped with ABS (anti-lock brake system) require ABS specific upper and lower brake line kits.  Failure to do so may result in compromised anti-lock braking ability.  Magnum Shielding upper brake line kits manufactured specifically for these applications are identified with the letter "ABS" printed directly on the brake hose.
